MQ-2 - Smoke Gas LPG Butane Hydrogen Gas Sensor

Availability: In Stock
Weight: 0.01kg
Package Size: 5.00cm x 3.50cm x 1.50cm
SKU: ELE-SEN-020

$1.50

Ex Tax: $1.50

Qty

Description

Features:

The MQ-2 is a semiconductor gas sensor that detects combustible gases and smoke, including LPG, propane, butane, hydrogen, and methane. It senses changes in SnO2 conductivity when exposed to gas, offering high sensitivity, long lifespan, and ease of use. Ideal for gas leak detection in homes and industrial systems.

Specifications:

Model: MQ-2
Sensor type: Semiconductor
Detection gases: LPG, propane, butane, hydrogen, methane, smoke
Concentration range: 300 to 10000 ppm (combustible gases)
Loop voltage (Vc): <=24V DC
Heater voltage (Vh): 5.0V +-0.2V (AC or DC)
Load resistance (RL): Adjustable
Heater resistance (Rh): 31 ohm +-3 ohm at room temp
Heater power consumption: <=900 mW
Sensing resistance (Rs): 2k ohm to 20k ohm (in 2000 ppm C3H8)
Sensitivity: Rs (in air) / Rs (in 1000 ppm isobutane) >=5
Concentration slope (alpha): <=0.6 (R5000ppm / R3000ppm CH4)
Standard operating temp: 20C +-2C
Standard humidity: 65% +-5% RH
Preheat time: Over 48 hours
