Thermostat Temperature Control W1209 DC 12V

Technical Parameters:

Temperature control range: -50~110°C
Resolution: -9.9~99.9 when 0.1 °C Other temperature range 1 °C
Temperature measurement accuracy: 0.1 °C
Control accuracy: 0.1 °C
Hysteresis accuracy: 0.1 °C
Refresh rate: 0.5 S
Input power: DC 12V
Measurement input: NTC (10K 0.5%) waterproof sensor
Output: 1 relay output, capacity = 20A 125VAC, 20A 14VDC
Environmental requirements: -10~60°C Humidity 20%-85%
Size: 48.5*40mm
Power consumption of the whole machine: quiescent current: ≤10MA Pull-in current: ≤65MA
