GY-273 HMC5883L Magnetometer Compass Sensor

Availability: In Stock
Weight: 0.00kg
Package Size: 8.00cm x 5.00cm x 0.10cm
SKU: ELE-SEN-065

$4.50

Ex Tax: $4.50

Qty

Description

Features:
The GY-273 HMC5883L Magnetometer Sensor provides accurate three-axis magnetic field measurement for electronic compasses and navigation systems. Using I2C communication, it offers a simple interface with Arduino, Raspberry Pi, and other microcontrollers. Its compact design and wide measuring range make it ideal for robotics, drones, and orientation detection applications.

Specifications:

Model: GY-273
Chip: HMC5883L
Measurement Range: ±1.3 to ±8 Gauss
Communication Interface: I2C (Address 0x1E)
Power Supply: 3V – 5V
Size: 1.8 × 1.3 cm
Slave Write Address: 0x3C
Slave Read Address: 0x3D
Operating Mode: 3-axis magnetic field detection
Usage: Magnetic field measurement, electronic compass, navigation, robotics
