Color Recognition Sensor TCS230 TCS3200

Availability: In Stock
Weight: 0.01kg
Package Size: 5.00cm x 5.00cm x 2.50cm
SKU: ELE-SEN-003

$5.50

Ex Tax: $5.50

Qty

Description

Features:

The Color Recognition Sensor TCS230/TCS3200 is a high-precision color detection module combining the TCS3200 RGB sensor chip with four white LEDs for uniform illumination. It detects visible colors using photodetectors filtered for red, green, blue, or clear light. The sensor outputs a square-wave frequency signal proportional to the intensity of the selected color channel, making it ideal for applications such as color sorting, test strip reading, ambient light monitoring, and color calibration.

Specifications:

Operating voltage: 2.7V to 5.5V
Output type: Frequency output (square wave)
Resolution: High-resolution light-to-frequency conversion
Output frequency scaling: Selectable via S0 and S1
Color filter selection: Selectable via S2 and S3
Output pin: OUT – frequency proportional to color intensity
Output enable: OE – active LOW
Power-down mode: Supported
LED control: Supports onboard LED illumination control
Communication: Direct frequency output to microcontroller
