Angle Sensor 1 Way SW-520D

Availability: In Stock
Weight: 0.00kg
Package Size: 8.50cm x 6.00cm x 0.08cm
SKU: ELE-SEN-001

$1.50

Ex Tax: $1.50

Qty

Description

Features:

The Angle Sensor 1 Way SW-520D detects tilt angles typically above 10 to 15 degrees, depending on its orientation. It provides a digital HIGH or LOW signal based on the tilt position. The module includes an adjustable potentiometer for tuning sensitivity, along with power and output status LEDs for easy monitoring. Its compact PCB design features mounting holes, making it suitable for seamless integration into electronics projects.

Specifications:

Operating voltage: 3.3V to 5V
Output type: Digital (0 or 1)
Max output current: >=15 mA
Tilt angle sensitivity: 10 degrees (varies with orientation)
Contact resistance: <10 ohm
Insulation resistance: 10 megaohm
Operating temperature: 0C to 80C
Comparator IC: LM393
Life expectancy: up to 100000 cycles
