3 Legs Slide Switch

Specification:
Model: SS12D00 SS12D00G3
Terminal Quantity: 3 Pcs
Working Power: 0. 5A 50V DC;
Contact Resistance: 30mΩ Max;
Insulation Resistance: 100mΩ Min at 500V DC;
Withstand Voltage: AC 500V for 1 min
Terminal Length: 3mm/ 0. 12";
Pin Pitch: 2. 54mm / 1";
Main Body Size(not include Pins & Knob): 8 x 4 x 3. 8mm/ 0. 31" x 0. 16" x 0. 15"(L*W*H)
Switch Total Size: 8 x 4 x 10mm/ 0. 31" x 0. 16" x 0. 39"(L*W*H);
Knob Size: 1. 5 x 1. 5 x 3mm/ 0. 06" x 0. 06" x 0. 12"(L*W*H);
Material(External): Plastic, Metal
Main Color: Silver Tone, Black;
